DMX-8(or DMX-4) Splitter is a DMX512 distribution amplifier It is specially designed for connection of DMX receivers (dimmers, color changers, moving lights,etc.) in a star configuration.
DMX-8(or DMX-4) can surmount the restriction that single RS485 can only connect 32 sets of equipment
The multiple output optically isolated DMX512 distribution amplifiers have become necessary in many DMX512 systems.
DMX-8(or DMX-4) provide total electrical ground isolation between different branches of the star. This greatly decreases problems with ground loops.
DMX-8(or DMX-4) amplifies and refits the DMX signal, that it makes the DMX data transmission more reliable.
Technical Specifications:
- Fully compliant to DMX-512 (1990) specification.
- Inputs and outputs are true RS-485 rated.
- 3 pin XLR input and a passive loop through.
- 8 or 4 way isolated DMX splitter output.
- Input isolated from outputs over 1000VDC.
- Outputs are isolated from each other over 1000VDC.
- Power supply, 90~240V AC 50Hz / 60Hz, 15W.
- 1U high 19 inch rack mount construction.
