| Technical Parameters |
| Light Source |
|
| Voltage |
AC 90-240V, 50-60Hz |
| Rated Power |
550W |
| Main Light Source |
7 × 60W (4-in-1 RGBW) High-Brightness LEDs |
| Filament Aura |
12 × 3W (3-in-1 RGB) LED Filament |
| Optical |
|
| Beam Angle |
7°–45° |
| Control |
|
| DMX Channels |
Built-in 20 / 21 / 30 / 36 / 57 / 78 / 93 CH Modes |
| Control Modes |
DMX512, Auto, RDM, Art-Net (Optional Installation Support) |
| Display |
LCD Display with Touch Buttons |
| Effects |
|
| Strobe |
1–25Hz with Multiple Strobe Effects |
| Dimming |
0–100% Linear Dimming with Four Curves (Linear / Square / I-Square / S-Curve) |
| Optical Effects |
High-precision integrated PMMA lens, high-transparency Quartz glass light pipe, soft wash effect, and latest Aura filament pixel effect. |
| Color Mixing |
RGBW color mixing with vivid saturated colors, soft pastel tones, white output, Tungsten Emulation, and Virtual Color Wheel. |
| Macro Effects |
Multiple built-in macros with foreground/background color control, speed, direction, 3D video mapping for beam pixels and Aura filaments, plus high-speed pan, tilt, and zoom. |
| Construction |
|
| Pan |
540° with 16-bit Fine Movement |
| Tilt |
270° with 16-bit Fine Movement |
| Temperature Control |
Intelligent temperature control with automatic fan speed adjustment and overheat protection. |
| Housing Material |
High Temperature-Resistant Plastic |
| IP Rating |
IP20 |
| Dimensions & Weight |
|
| Fixture Dimensions |
356 × 280 × 450 mm |
| Net Weight |
14.6 kg |
| Carton Size (1 pc/ctn) |
440 × 360 × 530 mm |
| Gross Weight (Carton) |
18.5 kg |
| Flight Case Size (2 pcs) |
700 × 400 × 690 mm |
| Gross Weight (2 pcs Flight Case) |
51 kg |
| Flight Case Size (4 pcs) |
880 × 595 × 705 mm |
| Gross Weight (4 pcs Flight Case) |
94.9 kg |
