CVS 4 MICRO Ceiling Speaker Tannoy

Product Features

• Coaxial full range low profile ceiling loudspeaker for installation applications

• 40 Watts continuous, 160 Watts peak power

• Shallow back can for limited cavity space

• 4" mineral loaded polypropylene driver with nitrile rubber surround for enhanced durability and long-term reliability

• 0.75" ferrofluid cooled soft dome neodymium high frequency driver

• Wide constant directivity dispersion for optimum coverage

• UL 1480 certified for fire-protected signalling systems

• UL 2043 certified for air-handling spaces

• UV and weather resistant UL 94 V-0 ABS front with plated steel fire can enclosure

• Multiple transformer taps for 70 V and 100 V line systems or 6 Ohm direct input

• Low insertion loss 15 W line transformer with easily accessible tapping switch

• Semi matt white finish fits unobtrusively in any environment

• Powder coated perforated steel mesh grille with dust protection

• Mounting C-ring and ceiling tile rails included

• Phoenix* connector with steel cover and strain relief clamping mechanism for fire rated cable

• Designed and engineered in the U.K.




  CVS 4 MICRO

  The CVS 4 MICRO is a compact 160-Watt shallow back can ceiling loudspeaker engineered to provide superb audio performance in both background and foreground music sound systems. Ideally suited for a wide variety of applications, from restaurants and hotels to houses of worship and businesses of all types, the CVS 4 MICRO offers the power handling, wide frequency response and low distortion more typically found in a studio reference monitor than a ceiling loudspeaker. The resulting sound is warm, with a nuanced and pristine clarity that envelopes the listener – without intruding.



  Exceptional Sound and Reliability

  The design comprises a 100 mm (4.00") mid bass driver with a coaxially mounted 19 mm (0.75") high frequency section mounted in a vented, injection moulded, paintable front baffle manufactured from UV/weather resistant UL94V-0 ABS material. The mineral loaded polypropylene cone material and nitrile rubber surround enhance durability and long-term reliability. Thanks to the shallow back can depth of less than 4" (98.3 mm), CVS 4 MICRO is perfect for applications where above-ceiling space is limited, but exceptional sonic quality and reliability are a requirement.



  Comprehensive Installation Package

  Supplied with an integral zinc-plated steel shallow back can, with recessed termination box, the CVS 4 MICRO satisfies the vast majority of installation application requirements. The removable locking connector has screw terminals for secure wire termination and “loop through” facility. Strain relief is provided by a clamping mechanism for use with plenum rated cable or conduit. Security toggle clamps make for quick and easy installation, while two tile support rails and one C-ring are also included in the package. A plaster (mud) ring is available as an optional accessory.

  Specification
