PLM 12K44 Amplifiers DSP 4 x 3.000w / 2Ohm Lab.Gruppen BP

Q: Which brand does PLM 12K44 belongs to?

PLM 12K44 belongs to Lab Gruppen . Lab Gruppen, DSP combined amplifier (Power Amplifier) from Sweden

Q: How long is the warranty of PLM 12K44?

PLM 12K44 is 24 months of warranty.

Product code: PLM 12K44 212,438

4.4/5 in 17 times

$5,152.46

In stock

Buy Now

Add to cart

Heavy / bulk items such as loudspeakers, digital mixers etc shipping via sea freight is recommended, contact [email protected] for more details

Price only applicable for overseas
Technical Support
Term of shipment: Ex-Works
Pick up at Hoang Bao Khoa LTD company
All shipping costs and risks, including export/import procedures, duty and others are on buyer’s account (Incoterm 2020)

Features

12,000 Watt Amplifier

4 Flexible Output Channels on Binding Post Connectors

Lake Digital Signal Processing

Digital Audio Networking for Touring Applications

12,000 Watt Amplifier with 4 Flexible Output Channels on Binding Post Connectors, LAKE Digital Signal Processing and Digital Audio Networking for Touring Applications

Shipping informations

Length

65.50 cm

Width

62.5 cm

Height

17.00 cm

Weight

20.50 kg

Official Distributor Certificate

Music Tribe distributor certificate

12,000 Watt amplifier with 4 flexible output channels and up to 5,900 Watts channel output for touring applications
LAKE digital signal processing for unparalleled loudspeaker management and system control
Integrated 8x8 channels of dual redundant Dante* digital audio networking with AES67 support
4 x 3,000 Watts into 2 Ohms, 4 x 3,000 Watts into 2.67 Ohms, 4 x 3,000 Watts into 4 Ohms, 4 x 1,900 Watts into 8 Ohms, 4 x 950 Watts into 16 Ohms, 4 x 3,000 Watts into Hi-Z 70 V, 4 x 3,000 Watts into Hi-Z 100 V
Proven and reliable Class-TD output stage with proprietary Intercooler high-efficiency cooling system
Rational Power Management (RPM) provides total flexibility to allocate available power across all 4 output channels
Best-in-class Power Factor Correction (PFC) with Current Draw Modelling reduces running costs and minimizes environmental impact
Under-Voltage Limiting (UVL) for continued operation during severe mains supply voltage drops
Dedicated on-board surveillance and load monitoring for complete peace of mind
Redundant audio inputs and on-board system surveillance for full system security
Backlit, white-on-black front panel display and menu navigation buttons
100 user presets for simple and efficient system configuration and set-up
3 front-to-rear airflow fans with temperature control for optimal speed and reduced noise
4 “LAKE Class” analog input channels with Iso-Float ground isolation
4 input channels of AES/EBU (AES3) digital audio supporting all standard sample rates up to 192 kHz with 24-bit resolution
2 Neutrik etherCON* RJ-45 ports provide dual redundant Dante interfaces and remote configuration via LAKE Controller and Dante Controller software
Balanced analog and AES/EBU audio inputs on Neutrik* XLR connectors
Rugged binding post output connectors
Detachable Neutrik powerCON* cable rated at 250 V / 32 A
Removable dust filter grilles for increased air circulation
Rugged 2U rackmount chassis for durability in touring applications
Designed and engineered in Sweden
