Parameter
|
Details
|
| Operating System |
Windows 10 64-bit (preinstalled) |
| CPU |
i7 |
| Memory |
8GB RAM |
| Storage |
128GB SSD |
| Screen |
15.6-inch foldable capacitive touch screen, can be connected to an external display |
| DMX Outputs |
2 DMX outputs |
| DMX Input |
1 composite input (can be set as output) |
| Channel Support |
Crack 256 domains, supports up to 65536 channel parameters |
| Electric Push Rods |
6 RGB backlit electric push rods |
| A/B Electric Push Rods |
2 RGB backlit A/B electric push rods |
| Control Elements |
1 total control push rod, 1 dimmer wheel |
| Encoders |
4 wear-resistant encoders (with Push function) |
| Network Port |
1 Gigabit network port, supporting MA net and Art-net |
| USB Ports |
4 USB ports |
| Work Light Port |
1 working light port |
| MIDI and Timecodes |
Supports MIDI and LTC/SMPTE timecodes |
| Power Supply |
Wide voltage AC 100V-240V 50/60Hz, built-in UPS |
| RDM Function |
Supports the RDM function |
