It is suitable for: Instrument
* Omni directional pick up pattern
* Flat frequency response
* Versatile mount clip
* Terminated with 4 pin mini XLR for easy wireless application
* Phantom power module with low cut and pad provided for wired application
SPECIFICATIONS
CX-500F |
Type |
Omni-directional Condenser |
Frequency Response |
20~20,000 Hz |
Sensitivity (at 1,000Hz) |
-58±3dB*(1.25mV)*0dB=1V/μbar |
Impedance |
1.5kΩ |
Max.SPL for 1% T.H.D. |
130 dB |
Signal-To-Noise Ratio |
68 dB |
Output Connector |
4P Mini XLR |
Power Supply |
1-5 VDC |
Current Consumption |
≤0.5mA |
Weight |
8 grams (including cable) |
Dimensions(mm) |
Ø6mm(W)*171mm(H) |
