Features:
The conductor adopts use of 99.99%OFC stranding with wire diameter of 2×0.32 mm.
The sheath and insulating layer are made of PVC material,very good transmission safety and linear sound transmission.
The thick copper braid is highly elastic.
Cable colour: Black Red Blue Grey Orange
Specification:
Jacket OD |
AWG |
No.of inner conductors |
Copper strandper conductor |
Shielding |
Shielding factor |
Temperaturerange |
Packaging |
Impedance |
PVC Φ6 |
23 |
2x0.25mm² |
32x0.10mm² |
Copper braided shielding with 96x0.10 |
95% |
-20℃∽+70℃(-4℃∽+158℃) |
100/300m roll |
≤10Ω/km、
|
