MDX2600 V2 Effects and Signal Processors Behringer

Product code: MDX2600 V2      405,854,541
4.67/5 in 3 times
Behringer
  • MDX2600 V2
  • LEFT
  • RIGHT
  • REAR
MDX2600 V2
LEFT
RIGHT
REAR

$124.13
In stock
ship note
Heavy / bulk items such as loudspeakers, digital mixers etc shipping via sea freight is recommended, contact [email protected] for more details
  • Price only applicable for overseas
  • Technical Support
  • Term of shipment: Ex-Works
  • Pick up at Hoang Bao Khoa LTD company
  • All shipping costs and risks, including export/import procedures, duty and others are on buyer’s account (Incoterm 2020)

Features

Reference-Class 2-Channel Expander/Gate/Compressor/Peak Limiter
Integrated De-Esser
Dynamic Enhancer and Tube Simulation
Reference-Class 2-Channel Expander/Gate/Compressor/Peak Limiter with Integrated De-Esser, Dynamic Enhancer and Tube Simulation

Shipping informations

Length
53.90 cm
Width
12.10 cm
Height
26.10 cm
Weight
2.31 kg

Official Distributor Certificate

Product Features

  • Switchable IKA (Interactive Knee Adaptation) program-adaptive compression circuitry combines the advantages of hard-knee and soft-knee characteristics

  • Integrated De-esser with switchable male/female voice recognition removes excessive sibilance from your vocal tracks

  • IGC (Interactive Gain Control) peak limiting circuitry combines clipper and program limiter for reliable and inaudible protection against signal peaks

  • Switchable dynamic Enhancer for brilliant, lively audio even with heavy compression

  • IRC (Interactive Ratio Control) expander/gate circuitry for virtually inaudible noise suppression

  • Switchable Tube simulation for the extra warmth and transparency of classic tube circuitry

  • Automatically or manually adjustable attack and release times

  • Switchable Low contour filter prevents "pumping" due to low-frequency dominated compression

  • Stereo couple function with independent output level settings

  • Switchable side chain input with monitor function

  • Separate 12-segment LED meters for input/output levels and gain reduction

  • Dedicated "traffic light" Threshold and De-esser level displays

  • Servo-balanced inputs and outputs with ¼" TRS and gold-plated XLR connectors

  • Relay-controlled hard bypass switch with auto bypass function in case of power failure

  • Internal switch-mode power supply (100 - 240 V~) for noise-free audio and low power consumption

COMPOSER PRO-XL MDX2600 V2

COMPOSER PRO-XL MDX2600 V2

The reference-class MDX2600 is a marvelous dual-channel Expander/Gate/Compressor/Peak Limiter that is ideal for: compressing mono/stereo signals and providing virtually inaudible noise suppression, without loss of high frequencies; increasing vocal presence and energy; and limiting, or smoothing out extremely-high signal peaks. Additionally, the MDX2600 features an integrated Dynamic Enhancer, De-Esser, Low-Contour filter and our revolutionary, switchable Tube simulation – for the extra warmth and transparency of classic tube circuitry. Put simply, the MDX2600 can do amazing things for your vocals or instruments – providing virtually everything you need for studio-quality dynamics processing!

Audio Dynamics Toolkit

Audio Dynamics Toolkit

THere are just a few of the MDX2600�s outstanding capabilities:

Switchable IKA (Interactive Knee Adaptation) � provides program-adaptive compression, combining all the advantages of both hard and soft-knee compression

IGC (Interactive Gain Control) � combines clipper and program limiter for reliable, inaudible protection against signal peaks

Enhancer � lets you emphasize the Bass, Midrange and Hi output at selectable frequencies for maximum punch, clarity and detail � without raising overall volume

Tube Simulation � provides the extra warmth and transparency of classic tube circuitry, creating a sound rich in harmonic content

De-Esser � �must-have� tool with switchable male/female voice recognition for reducing sibilance, while preserving natural voice timbre � often used to enhance upper-mid, to high-frequency smoothness in vocals, drum overheads, strings, etc.

Side Chain � allows insertion of graphic/parametric EQ to reduce specific frequencies � also often used to �tighten up� tracks using an internal or external signal to trigger compression, or gating of signal being processed (ex. using bass guitar signal to un-gate kick drum)

Stereo Couple � links both channels, allowing Channel 1 dials and switches to provide dynamics control over both channels (true stereo processing)



Revolutionary Tube Simulation

Revolutionary Tube Simulation

The secret behind the COMPOSER PRO-XL MDX2600’s incredible sound is our Tube Modeling processor, which exudes the very essence of tube and compression. This amazing circuitry accurately emulates the performance characteristics of highly sought-after classic tube compressors, creating a sound that is so rich in harmonic content – you’ll wonder where we hid the tubes!

Options Abound

Options Abound

The MDX2600 features amazingly-accurate 12-segment LED meters for In/Out Level and Gain Reduction, switchable +4 dBu or -10 dBV operating level, Side Chain I/O, and servo-balanced XLR and 1/4" Inputs and Outputs. Best of all, the COMPOSER PRO-XL MDX2600 takes up just a single rackspace.

Sound Value

Sound Value

The incredible MDX2600 is the ideal solution for becoming the master of your dynamics. With its flexible routing options, all the I/O you could ask for, plus a host of other professional features – the MDX2600 is an exceptional tool for your live shows – and an absolute “must-have” for your studio! Check out the COMPOSER PRO-XL MDX2600 at your Behringer dealer, or place your order online today.



Specification

Audio Inputs

Type

XLR and 1/4" TRS connectors, servo-balanced

Impedance
+4 dBu

50 kΩ balanced, 50 kΩ unbalalanced @ 1 kHz

-10 dBV

50 kΩ balanced, 100 kΩ unbalanced @ 1 kHz

Operating Level

+4 dBu / -10 dBV, switchable

Max. input level

 +22 dBu, balanced and unbalanced

CMRR

 Typically 60 dB @ 1 kHz

Audio Outputs

Type

 XLR and 1/4" TRS connectors, servo-balanced

Impedance

 100 Ω balanced, 50 Ω unbalanced @ 1 kHz

Max. output level

 +21 dBu, balanced and unbalanced

Sidechain Inputs

Type

1/4" TS connector, unbalanced

Impedance

10 kΩ

Max. input level

 +20 dBu

Sidechain Outputs

Type

1/4" TS connector, unbalanced

Impedance

 50 Ω

Max. output level

+21 dBu

System Specifications

Frequency range

 10 Hz to 70 kHz, +0/-3 dB

S/N ratio

115 dB, unweighted

THD

 0.02% typ. @ +4 dBu, 1 kHz, unity gain

Crosstalk

 -90 dB @ 1 kHz

Expander / Gate Section

Type

 IRC (Interactive Ratio Control) expander

Threshold

 OFF to +10 dB, variable

Ratio

 1:1 to 1:8, variable

Attack

< 1 msec / 50 dB, program-dependent

Release

SLOW: 100 msec/1 dB

  FAST: 100 msec/100 dB, variable

Compressor Section

Type

IKA (Interactive Knee Adaptation) compressor

Threshold

-40 to +20 dB, variable

Ratio

1:1 to ∞:1, variable

Attack / release

 Manual or automatic, variable

Manual attack time

0.3 msec/20 dB to 300 msec/20 dB, variable

Manual release time

0.05 sec/20 dB to 5 sec/20 dB, variable

Auto characteristic

Wave adaptive compressor

Auto attack time

Typically 15 msec for 10 dB, 5 msec for 20 dB, 3 msec for 30 dB


Auto release time

 Typically 125 dB/sec, program-dependent

Output

-20 to +20 dB, variable

Peak Limiter Section

Type

IGC (Interactive Gain Control) peak limiter

Level

0 dB to OFF (+21 dBu), variable

Level 1 limiter type

Clipper

Attack

“Zero”

Release

 “Zero”

Level 2 limiter type

 Program limiter

Attack

 Typically <5 msec, program-dependent

Release

Typically 20 dB/sec, program-dependent

Dynamic Enhancer Section

Type

IDE (Interactive Dynamic Enhancer)

Filter frequency

 2.5 kHz (lower cut-off frequency)

Characteristic

 High-pass filter (6 dB/oct.)

Boost

Max. 28 dB @ 7.5 kHz

De-Esser Section

Type

VAD (Voice-Adaptive De-Esser)

Filter Frequencies

 8.6 kHz (Female), 7.5 kHz (Male)

Filter bandwidth

Program-dependent

Level reduction

 Max. 15 dB

Power Supply, Voltage, Current Consumption

Switch mode power supply

Autorange, 100-240 V~ 50/60 Hz

Power consumption

15 W

Mains connector

 Standard IEC receptacle

Dimensions / Weight

Dimensions (H x W x D)

44 x 483 x 149 mm (1.7 x 19.0 x 5.9")

Weight

1.7 kg (3.7 lbs )
