Effects and Signal Processors Behringer MDX4600 V2, Signal Processors Gate/Compressor/Limiter Behringer MDX4600 V2

Name: Effects and Signal Processors Behringer MDX4600 V2, Signal Processors Gate/Compressor/Limiter Behringer MDX4600 V2
Brand: Behringer
SKU: HBK25375
Price: 0.37 USD
Availability: InStock
Rating: 4.67 (3 reviews)

MDX4600 V2 Effects and Signal Processors Behringer

Product code: MDX4600 V2 473,231,764

4.67/5 in 3 times

~~$124.13~~-22%

$96.42

In stock

Buy Now

Add to cart

Warranty 24 months

Heavy / bulk items such as loudspeakers, digital mixers etc shipping via sea freight is recommended, contact [email protected] for more details

Price only applicable for overseas
Technical Support
Term of shipment: Ex-Works
Pick up at Hoang Bao Khoa LTD company
All shipping costs and risks, including export/import procedures, duty and others are on buyer’s account (Incoterm 2020)

Features

Reference-Class 4-Channel Expander/Gate/Compressor/Peak Limiter

Dynamic Enhancer

Low Contour Filter

4Reference-Class 4-Channel Expander/Gate/Compressor/Peak Limiter with Dynamic Enhancer and Low Contour Filter

Shipping informations

Length

53.90 cm

Width

12.10 cm

Height

26.10 cm

Weight

2.42 kg

Official Distributor Certificate

Music Tribe distributor certificate

Product Features

Switchable IKA (Interactive Knee Adaptation) program-adaptive compression circuitry combines the advantages of hard-knee and soft-knee characteristics
IRC (Interactive Ratio Control) expander/gate circuitry for virtually inaudible noise suppression
Switchable dynamic Enhancer for brilliant, lively audio even with heavy compression
IGC (Interactive Gain Control) peak limiting circuitry combines clipper and program limiter for reliable and inaudible protection against signal peaks
Switchable Low contour filter prevents "pumping" due to low-frequency dominated compression
Stereo couple function selectable for channels 1/2 and 3/4
Separate 8-segment LED meters for input/output levels and gain reduction
Selectable operating level (+4 dBu/-10 dBV)
Servo-balanced inputs and outputs with ¼" TRS and gold-plated XLR connectors
Internal switch-mode power supply (100 - 240 V~) for noise-free audio and low power consumption

MULTICOM PRO-XL MDX4600 V2

The reference-class MDX4600 is a marvelous 4-channel Expander/Gate/Compressor/Peak Limiter that is ideal for: compressing mono/stereo signals and providing virtually inaudible noise suppression, without loss of high frequencies; increasing vocal presence and energy; and limiting, or smoothing out extremely-high signal peaks. Additionally, the MDX4600 features an integrated Dynamic Enhancer and Low-Contour filter to provide the ultimate in signal enrichment. Put simply, the MDX4600 can do amazing things for your vocals or instruments – providing virtually everything you need for studio-quality dynamics processing!

Audio Dynamics Toolkit

Here are just a few of the MDX4600�s outstanding capabilities:

Switchable IKA (Interactive Knee Adaptation) � provides program-adaptive compression, combining all the advantages of both hard and soft-knee compression
IRC (Interactive Ratio Control) Expander/Gate � ideal solution for noise floor reduction vs. applying notch filters and various equalizers for virtually inaudible noise suppression
Enhancer � lets you emphasize the Bass, Midrange and Hi output at selectable frequencies for maximum punch, clarity and detail � without raising overall volume
IGC (Interactive Gain Control) Peak Limiter � combines clipper and program limiter for reliable, inaudible protection against signal peaks
Stereo Couple � links 1/2 and 3/4 channels, allowing dials and switches of Channels 1 and 3 to provide dynamics control over Channels 2 and 4, respectively (true stereo processing)

Options Abound

The MDX4600 features amazingly-accurate, 8-segment LED meters for In/Out Level and Gain Reduction, switchable +4 dBu or -10 dBV operating level, Side Chain I/O, and servo-balanced XLR and 1/4" Inputs and Outputs. Best of all, the MULTICOM PRO-XL MDX4600 takes up just a single rackspace.

Sound Value

The incredible MDX4600 is the ideal solution for becoming the master of your dynamics. With its flexible routing options, all the I/O you could ask for, plus a host of other professional features – the MDX4600 is an exceptional tool for your live shows – and an absolute “must-have” for your studio! Check out the MULTICOM PRO-XL MDX4600 at your BEHRINGER dealer, or place your order online today.

Specification

Audio Inputs

Type	XLR and 1/4" TRS connectors, servo-balanced
Impedance
+4 dBu	50 kΩ balanced, 50 kΩ unbalalanced @ 1 kHz
-10 dBV	50 kΩ balanced, 100 kΩ unbalanced @ 1 kHz
Operating Level	+4 dBu / -10 dBV, switchable
Max. input level	+22 dBu, balanced and unbalanced
CMRR	Typically 60 dB @ 1 kHz

Audio Outputs

Type	XLR and 1/4" TRS connectors, servo-balanced
Impedance	100 Ω balanced, 50 Ω unbalanced @ 1 kHz
Max. output level	+21 dBu, balanced and unbalanced

System Specifications

Frequency range	10 Hz to 70 kHz, +0/-3 dB
S/N ratio	115 dB, unweighted
THD	0.02% typ. @ +4 dBu, 1 kHz, unity gain
Crosstalk	-90 dB @ 1 kHz

Expander / Gate Section

Type	IRC (Interactive Ratio Control) expander
Threshold	OFF to +10 dB, variable
Ratio	1:1 to 1:8, variable
Attack	< 1 msec / 50 dB, program-dependent
Release	SLOW: 100 msec/1 dB FAST: 100 msec/100 dB, variable

Compressor Section

Type	IKA (Interactive Knee Adaptation) compressor
Threshold	-40 to +20 dB, variable
Ratio	1:1 to ∞:1, variable
Auto characteristic	Wave adaptive compressor
Auto attack time	Typically 15 msec for 10 dB, 5 msec for 20 dB, 3 msec for 30 dB
Auto release time	Typically 125 dB/sec, program-dependent
Output	-20 to +20 dB, variable

Peak Limiter Section

Type	IGC (Interactive Gain Control) peak limiter
Level	0 dB to OFF (+21 dBu), variable
Level 1 limiter type	Clipper
Attack	“Zero”
Release	“Zero”
Level 2 limiter type	Program limiter
Attack	Typically <5 msec, program-dependent
Release	Typically 20 dB/sec, program-dependent

Dynamic Enhancer Section

Type	IDE (Interactive Dynamic Enhancer)
Filter frequency	2.5 kHz (lower cut-off frequency)
Characteristic	High-pass filter (6 dB/oct.)
Boost	Max. 28 dB @ 7.5 kHz

Power Supply, Voltage, Current Consumption

Switch mode power supply	Autorange, 100-240 V~ 50/60 Hz
Power consumption	18 W
Mains connector	Standard IEC receptacle

Dimensions / Weight

Dimensions (H x W x D)	44 x 483 x 149 mm (1.7 x 19.0 x 5.9")
Weight	1.8 kg (4.0 lbs )
