NuQ118B Passive Subwoofer Turbosound

Product code: NuQ118B      557,822,824
4.67/5 in 3 times
Turbosound
  • Rear
  • Right
  • Left
  • Front
Rear
Right
Left
Front

$567.24
In stock
ship note
Heavy / bulk items such as loudspeakers, digital mixers etc shipping via sea freight is recommended, contact [email protected] for more details
  • Price only applicable for overseas
  • Technical Support
  • Term of shipment: Ex-Works
  • Pick up at Hoang Bao Khoa LTD company
  • All shipping costs and risks, including export/import procedures, duty and others are on buyer’s account (Incoterm 2020)

Features

Band pass subwoofer for portable PA and installation applications
600 Watts continuous, 2,400 Watts peak power
 18 inch Band Pass Subwoofer for Portable PA and Installation Applications



Shipping informations

Length
83.50 cm
Width
70.70 cm
Height
83.30 cm
Weight
65.31 kg

Official Distributor Certificate

Product Features

  • Band pass subwoofer for portable PA and installation applications

  • 600 Watts continuous, 2,400 Watts peak power

  • Double suspension 18" low frequency driver with inside/outside wound coil

  • Low distortion dual port design for maximum sound pressure level

  • 18 mm (3/4") birch plywood enclosure with hard wearing semi matt black paint finish

  • Integral M10 rigging points for ease of installation

  • 35 mm pole mount to support satellite speaker

  • Neutrik speakON* NL4 connectors for reliable long life operation

  • Designed and engineered in the U.K.

NuQ118B

NuQ118B

The 2,400 Watt NuQ118B is an 18" dual ported bandpass enclosure that is optimally tuned for extended low frequency response. Engineered to work in conjunction with TURBOSOUND loudspeaker management systems, the NuQ118B provides very high output FOH performance and is ideally suited for a wide range of music and live sound reinforcement applications.

The NuQ118B features a powerful, double suspension 18" low frequency driver that utilizes a specialised inside/outside wound voice coil for higher magnetic density, better heat dissipation, high power handling capacity, and improved efficiency. For its size and operating bandwidth, the NuQ118B delivers extremely high output that is virtually distortion free - even in the most demanding applications.

Finished in a highly durable semi matt black paint, the cabinet is constructed from 18 mm(¾ ")birch plywood and includes: multiple threaded rigging points; a 35 mm pole socket; integrated carry handles for convenient transport - and high impact interlocking corners for ground stacking stability. The rear panel connector plate carries Neutrik speakON* NL4 connectors, with switchable input and link connections to accommodate standalone subwoofer applications, or subwoofer and satellite speaker connectivity via 4 core speaker cabling.

Architecture & Engineering Specifications

The speaker shall be of the passive subwoofer type consisting of one 18" (460 mm) LF driver. Performance specifications of a typical production unit shall meet or exceed the following: frequency response, measured with swept sine wave input, shall be flat within ±3 dB from 40 Hz to 150 Hz and within -10 dB from 33 Hz to 150 Hz. Nominal dispersion shall be “half space.” Nominal impedance shall be 8 Ohms. Power handling shall be 600 Watts continuous, 2,400 Watts peak. Sensitivity, measured on axis, mean averaged over stated bandwidth, shall be 100 dB, 1 Watt @ 1 metre. Maximum SPL (peak), measured at 1 metre with music program at stated amplifier input, shall be 134 dB. Dimensions: 773 mm high x 700 mm wide x 579 mm deep (30.4" x 27.6" x 22.8"). Net weight: 56.5 kg (124.6 lbs). The loudspeaker system shall be the TURBOSOUND NuQ118B . No other loudspeaker shall be acceptable unless submitted data from an independent test laboratory verifies that the above combined performance / size specifications are equaled or exceeded.

Specification

System

Frequency Response 40 Hz – 150 Hz ± 3 dB
33 Hz – 150 Hz - 10 dB
Nominal Dispersion Half space
Power Handling (IEC) 600 W continuous, 2,400 W peak
Sensitivity 100 dB (1 W @ 1 m)
Maximum SPL 128 dB continuous, 134 dB peak
Impedance 8 O
Components 1 x 18" (460 mm) LF driver

Enclosure

Connectors 2 x Neutrik speakON* NL4
Wiring
Dimensions (H x W x D) 773 x 579 x 700 mm (30.4 x 22.8 x 27.6")
Net Weight 56.5 kg (124.6 lbs)
Construction 18 mm (¾") birch plywood
Finish Semi matt black paint
Grille N/A
Flying Hardware M10 x 16 points

$567.24
In stock
Only 10 left, order soon!
ship note
Heavy / bulk items such as loudspeakers, digital mixers etc shipping via sea freight is recommended, contact [email protected] for more details
  • Price only applicable for overseas
  • Technical Support
  • Term of shipment: Ex-Works
  • Pick up at Hoang Bao Khoa LTD company
  • All shipping costs and risks, including export/import procedures, duty and others are on buyer’s account (Incoterm 2020)

Contact

Business hours

Monday 7:30 AM - 5:00 PM
Tuesday 7:30 AM - 5:00 PM
Wednesday    7:30 AM - 5:00 PM
Thursday 7:30 AM - 5:00 PM
Friday 7:30 AM - 5:00 PM
Saturday 7:30 AM - 5:00 PM

Software

FAQs

Does the company offer free shipping?

Free shipping for local order over $22. Oversea buyers will pay for shipping cost under Ex-work term.

NuQ118B has a discount?

This price is the best to you now.

Which brand does NuQ118B belongs to?

NuQ118B belongs to Turbosound. Turbosound, a 48-year-old famous British speaker company founded by Mr. Tony Andrews

How long is the warranty of NuQ118B?

NuQ118B is 24 months of warranty.

Does HoangBaoKhoa support for installment?

Yes, installment payment via credit card.
