Home Page » Outdoor » XLR Connectors » RCX3M-Z-000-1 3 pole male XLR cable connector Rean

RCX3M-Z-000-1 3 pole male XLR cable connector Rean

Name: 3 pole male XLR cable connector Rean RCX3M-Z-000-1
Brand: Rean
SKU: HBK48171
Availability: InStock
Rating: 4.67 (3 reviews)

Product code: RCX3M-Z-000-1 507

4.67/5 in 3 times

$1.03

In stock

Buy Now

Add to cart

Heavy / bulk items such as loudspeakers, digital mixers etc shipping via sea freight is recommended, contact [email protected] for more details

Price only applicable for overseas
Technical Support
Term of shipment: Ex-Works
Pick up at Hoang Bao Khoa LTD company
All shipping costs and risks, including export/import procedures, duty and others are on buyer’s account (Incoterm 2020)

Features

IP65 rating provides outdoor protection under mated condition

Chrome&Black plated with fashionable finish and better abrasion performance

UL94 V-0 rated materials

3 pole male XLR cable connector with IP65 dust-water proof design.

Shipping informations

Length

12 cm

Width

12 cm

Height

5 cm

Weight

0.4 kg

Official Distributor Certificate

Rean distributor certificate

Technical Information

Product
Title	RCX3M-Z
Connection Type	XLR
Gender	male

Electrical
Contact resistance	≤ 5 mΩ
Dielectric strength	1,5 kVdc
Insulation resistance	> 10 GΩ (initial)
Rated current per contact	16 A
Rated voltage	< 50 V

Mechanical
Cable O.D.	5.0 - 8.0 mm
Insertion force	≤ 60 N
Withdrawal force	≤ 60 N
Lifetime	> 1000 cycles
Wiresize	Max. 1.5 mm2
Wiresize	Max. 16 AWG
Wiring	Solder contacts
Locking device	Latch lock

Material
Bushing	Polyamide
Contact plating	Tin (-000 & - 001) / AU (-002)
Contacts	Brass
Insert	Polyamide (UL94-V0)
Locking element	Zinc diecast
Shell	Zinc diecast
Shell plating	Chrome (-000) / Black (-001 & -002)
Strain relief	Polyamide
Sealing jacket	Rubber

Environmental
Flammability	UL 94-V0
Protection class	IP65 (Mated)
Standard compliance	IEC 61076-2-103
Solderability	Complies with IEC 68-2-20
Temperature range	-20 °C to +70 °C
