TECHNICAL PARAMETERS
Light source
Input voltage: AC110-220V, 50-60Hz; electronic ballast and AC/DC switching power supply
Display: color LCD display
Keys: touch keys
Bulb: Philips MSD Platinum 420W Lamp
Optical
Lens: Three-layer high-precision multi-group glued optical lens, 6-layer coating
Motor: The latest technology research and development of high-silent motors with high-tech drive software, so that each functional motor has super-fast response and accurate positioning under silent movement, and users can easily achieve fast scene switching during use
Speed: X-axis can reach 2.2/S; Y-axis can reach 1.1/S
Strobe: Turn off the strobe, the lamp automatically half-power, energy saving and environmental protection, Electric focus, beam angle 0~2.4°;
Controls
Control channel: 16CH/20CH
Effect
Color: Italian color filter, 14 bright and beautiful colors + white light, Pattern: 17 fixed pattern pieces + white light
Prism: 8 prisms-16 prisms-8+16 superimposed prisms, moving effect, atomization function; 0~100% mechanical dimming, support mechanical strobe and adjustable speed strobe effect, support strobe macro function;
Construction
Adopting photoelectric reset system, it can automatically retrieve and reset when an accidental misoperation occurs. Horizontal: 540°, resolution 8Bit/16Bit;
Vertical: 270°, resolution 8Bit/16Bit. Overheat protection.
Weight&Dimension
Light hook: 2 pcs
Net weight: 15.2KG
Size: 31*31.5*52CM
