EW-DX Dante modes: Single Cable (control + Dante), Split (separate networks), Redundant (backup network). Configure and route via Dante Controller. Learn more at this article.
Dante connection mode options
Dante Connection Mode options for EW DX EM 2 Dante - these can be changed in System > Network Mode on the receiver, depending on the intended deployment configuration.
EW DX EM 4 Dante connection modes
Dante Connection Mode options for EW DX EM 4 Dante:
Single Cable Mode
Single Cable Mode is the default network, which incorporates Control and Dante capability over a single cable together. In this way, receivers can be daisy chained from secondary to primary of the next receiver.
SPLIT Mode is designed for a dedicated Dante network, whereby Control and Dante are physically separate.
Redundant Mode
Redundant mode is for two entirely separate networks as a safety measure, where if one goes down, another is intact and operational.
Further information
For more information and best practice guidance, please refer to our EW DX Dante Network Connection Guide.
Dante subscriptions and routing
Dante subscriptions are made within Dante Controller on the Routing tab, where each microphone channel can be routed to a Dante mixer channel or DSP for further processing.
