AWM UHF (470 – 694 MHZ) Wall mount antenna

Name: AWM UHF (470 – 694 MHZ)
Brand: Sennheiser
SKU: HBK60088
Availability: InStock
Rating: 4.67 (3 reviews)

Product code: AWM UHF (470 – 694 MHZ) 15

4.67/5 in 3 times

Price only applicable for overseas
Technical Support
Term of shipment: Ex-Works
Pick up at Hoang Bao Khoa LTD company
All shipping costs and risks, including export/import procedures, duty and others are on buyer’s account (Incoterm 2020)

Features

Active directional antenna

Adjustable gain settings for different cable length

Wall, ceiling or mic stand mounting options

AWM Antenna is an active directional antenna for use with Evolution Wireless Digital microphone systems.

Official Distributor Certificate

Sennheiser distributor certificate

AWM Antenna is an active directional antenna for use with Evolution Wireless Digital microphone systems. The AWM antenna is designed to enhance the wireless performance of your Evolution Wireless Digital system and can be installed quickly and easily in any room, on a vertical (wall) or horizontal (ceiling) surfaces. The AWM UHF can be connected to any stationary Evolution Wireless Digital receiver or EW-D ASA antenna splitter. Sennheiser EW-DX simplifies your professional workflow by utilizing refined technologies to deliver a digital UHF system that can be scaled with ease. With its advanced feature set and hardware options, classrooms, corporate campuses, and live performance productions benefit from a network-ready system that is designed to integrate seamlessly.

Features

Active directional antenna
Adjustable gain settings for different cable length
Wall, ceiling or mic stand mounting options
Power supply via BNC (EW-D ASA / EW-DX EM 4 Dante) or optional power supply<br>
In combination with EW-DX EM 2 (Dante) or EW-D EM, a power supply ( EW-D POWER SUPPLY) is required<br>

Top Specs

Specification	Value
Weight	Approx. 700 g
Frequency Range	470 – 694 MHz
Power Consumption	12 V DC (9 – 18 V DC) / max. 100 mA @ 12 V
Connection	BNC female, DC coupled
Connectors	BNC

Tech Specs

Frequency Specifications

Specification	Value
Frequency range	470 – 694 MHz

Connectivity

Specification	Value
Connection	BNC female, DC coupled
Connectors	BNC

Ambient Conditions

Specification	Value
Operating relative humidity	5 to 95 %
Operating temperature	-10 °C to +55 °C (14 °F to 131 °F)

Battery & Power

Specification	Value
Battery included	N
Power consumption	12 V DC (9 – 18 V DC) / max. 100 mA @ 12 V

Electrical Properties

Specification	Value
Impedance	50
Input voltage	12 V DC (9 – 18 V DC) / max. 100 mA @ 12 V
Output power	Approx. +18 dBm

Dimensions

Specification	Value
Height	53 mm
Width	180 mm
Length	180 mm
Weight	Approx. 700 g

UHF antenna 470-694 MHz AWM 470-694 MHz audio antenna 470 MHz UHF antenna Sennheiser AWM
