| Using Voltage |
AC100V-240V, 50/60Hz |
| Rated Power |
520W |
| Light Source |
Philips 420W bulb |
| Beam Angle |
1.8° |
| Lens |
156MM |
| Control Channel |
20/16 standard DMX channels |
| Operation Mode |
Voice control, Auto, Master-Slave, DMX512, RDM |
| Color Disk |
14 colors + white light, bidirectional rainbow effect, half-color effect, linear color adjustment |
| Fixed Gobo |
13 patterns + white circle, variable speed shaking |
| Prism |
Two independent prism disks, standard 8 and 24 prisms, 8, 16, 24, 48 prisms optional |
| Focus |
High-precision multi-layer coated glass lens, DMX linear high-definition focus, adjustable clarity |
| Atomization |
Built-in atomization mirror for softening effect, colorful effect |
| Strobe |
1-15 times/second high-speed strobe effect |
| Dimming |
0-100% mechanical linear dimming |
| Horizontal/Vertical Movement |
Horizontal: 540°, Vertical: 270°, 16-bit precision, auto return correction, fast, smooth operation with low noise |
| Display Interface |
LCD liquid crystal display, switchable between Chinese and English |
| Lamp Housing |
Nylon flame-retardant, self-extinguishing, streamlined design |
| RDM Function |
Remote address code setting |
| Console Control |
Light control with console, delayed on/off light bulb |
| Protection Level |
IP20 |
| Overall Dimensions |
L325×W250×H520mm |
| Packaging Dimensions |
L415×W325×H605mm |
| Net Weight |
13 KGS |
| Gross Weight |
15.5 KGS |
