| Light Source |
| Input Voltage |
AC 100V–240V, 50/60 Hz |
| Rated Power |
1300 W |
| Light Source |
1200W LED Module |
| Color Temperature |
7300K |
| Light Source Lifetime |
>20,000 hours |
| Optical |
| CRI |
Standard Mode Ra > 70 / High CRI Mode Ra > 90 (Switchable) |
| Zoom Angle |
5°–50° linear high-speed zoom |
| Output Lens Diameter |
138 mm |
| Illuminance |
28,500 lux @ 10 m |
| Controls |
| Control Channels |
39 CH |
| Control Protocol |
DMX512 / RDM |
| Display |
2.8-inch touchscreen, dual-language (Chinese/English), 180° reversible display |
| Energy-Saving Mode |
Auto sleep when signal is disconnected |
| Software Upgrade |
Upgradeable via DMX signal cable |
| Effect |
| Color Mixing |
Interchangeable CMY seamless mixing + linear CTO (7000–2600K) |
| Color Wheel |
1 color wheel with 4 colors, step/linear change, rainbow & flow effects |
| Framing System |
| Framing Shutters |
4 independently controllable shutters, rotatable system (90°) |
| Rotating Gobo Wheel |
7 interchangeable glass gobos, bi-directional rotation |
| Gobo Size |
OD 30mm ±0.2mm / ID 16mm / Thickness 1.1mm |
| Fixed Gobo Wheel |
6 metal gobos + open white, variable-speed shake effect |
| Dynamic Effects Wheel |
Simulated effects such as flame flicker and flowing water |
| Prism |
1 × 3-facet prism, bi-directional rotation |
| Dimming |
0–100% linear dimming |
| Strobe |
Electronic strobe with variable speed |
| Frost |
1 independent frost filter, 0–100% linear adjustment |
| Iris |
Motorized iris, 5–100% linear adjustment |
| Construction |
| Pan/Tilt |
540° pan / 270° tilt, 16-bit precision with auto repositioning |
| Positioning System |
Magnetic encoder positioning |
| Cooling System |
Copper heat pipe + intelligent variable-speed fan with thermal sensors |
| Signal Interface |
3-pin & 5-pin XLR input/output |
| Housing |
Flame-retardant, high-temperature resistant nylon with folding hook |
| Operating Temperature |
-20°C to 40°C |
| IP Rating |
IP20 |
| Weight |
| Net Weight |
38 kg |
