| Input voltage |
AC 100V/120V/200V/220V /230V/240V
50/60Hz |
| Power |
700W@220V |
| LED light source |
Strobe Tube LEDS
- LED Type: 3535 5W 6500K LEDs
- LED Count: 144
- LED Colors: Cool-White
- LED Segments: 16
Strobe Panel LEDs
- LED Type: 5050SMD 2W RGBW 4 in1
- LED Count: 242
- LED Colors: Cool-White
- LED Segments: 32 (2x16)
|
| Working lifetime |
50000h |
| Dimmer |
0-100% linear dimming |
| Strobe |
Electric strobe，0.3-20pcs/sec
Max 20 Hz |
| Control mode |
International standard DMX 512signal，3 Pin (5 Pin) DMX512 interface RDM |
| Wireless |
2.4 GHz W-DMX™ (optional) |
| Art-Net |
(optional) 3 channel modes
- Master-slave
- Stand-alone mode
- Self-test mode
|
| Otherfunctions |
Adjustable horizontal and vertical speed
Display fixture using time
Display software version number
Modular structure for easy maintenance
Speed-regulating radiator |
| Connector Power |
Seetronic Powercon Ture1 |
| DMX |
Seetronic XLR Cable Connector |
| Art-net |
Seetronic RJ45 Connector |
| Shell and protection level |
High-strength casting aluminum alloy，IP66 black shell（white optional） |
| Working temperature |
-20°C～40°C |
| Weight |
8.9 Kg |
