| Light Source |
| Light Source |
19 x 40W RGBW 4-in-1 LED |
| LED Lifetime |
≥ 50,000 hours |
| Power Voltage |
AC100-240V, 50-60Hz |
| Power Consumption |
650W |
| Optical |
| Beam Angle |
3.5° - 48° |
| Controls |
| Control Modes |
DMX512, Auto, Sound, Master, Manual, RDM, ArtNet (Optional) |
| DMX Channels |
21 / 23 / 35 / 78 / 92 / 97 / 99 / 76 (DMX + ArtNet) |
| Display |
TFT 1.8-inch Display |
| Construction |
| Data In/Out Socket |
IP65 3-pin XLR sockets |
| Power Socket |
IP65 Power-Con in/out |
| Housing Material |
Die-casting + flame-retardant black carbon fiber |
| Pan |
540° (accuracy 2.11°/step, fine-tuning 0.008°) |
| Tilt |
270° (accuracy 0.86°/step, fine-tuning 0.0034°) |
| Pan/Tilt Resolution |
Automatic position correction |
| Max. Connection |
5 units (240V, 50Hz) with 2.5mm² power cable
3 units (100V, 60Hz) with 2.5mm² power cable |
| Protection Rating |
IP65 |
| Weight & Dimension |
| Dimension |
341 x 250 x 463 mm |
| Net Weight |
14 kg |
| Carton Package |
58 x 37 x 45 cm (1 unit) |
| Gross Weight (Carton) |
17 kg |
| Flight Case |
83 x 74 x 67 cm (4 units) |
| Gross Weight (Flight Case) |
96 kg |
| Features |
Full-range dimming with 65,536 levels of precision;
Fast strobe 1–25Hz;
Individual LED control;
3-in-1 effects: WASH, Beam, Bee Eye;
Preset multiple color macros;
Preset multiple effect macros |
| Configuration |
Signal cable X1
Power cable X1
User manual x1 |
