Updating the firmware ensures your Lake system operates stably, remains compatible with the latest software, and performs at its best. The following guide explains in detail how to update the firmware for your Lake Frame or PLM+ / D Series device using the Lake Controller software.
Preparation Before Updating
Before you begin, make sure to:
-
Download the latest version of Lake Controller from the official website: labgruppen.com/support/download-software
-
Connect your Lake Frame device to your computer via LAN
-
Ensure a stable power supply throughout the update process to prevent interruptions
Open the Lake Update Utility
On your computer, navigate to:
C: → Program Files (x86) → Lake
-
Open the folder containing the version of Lake Controller you want to use for the firmware (this may be the latest version or one compatible with your current system).
-
Run the Lake Update Utility application.
-
Select the network adapter currently connected to the device.
Check the Current Firmware Version
After launching the application:
-
The system will automatically scan and display all connected Lake Frame devices.
-
You can view the current firmware version for each device.
-
If a red X appears next to a device, it means the firmware is not yet updated to a version compatible with the current Lake Controller.
Perform the Firmware Update
-
Select the device you want to update from the list.
-
Click Update to start the process.
-
Read the information displayed in the update window carefully, then click OK to confirm.
During the update process:
-
For PLM+ and D Series devices, the unit will automatically power cycle - this feature was introduced starting from Lake 6.5 and later.
-
For older Lake devices, you must manually power cycle the unit by unplugging the power cable (do not simply switch to Standby mode) when prompted.
Complete the Update
Once the update is complete:
-
The Lake Updater will display a completion message.
-
Wait a few minutes for the device to restart and load the new firmware version.
-
When done, a green check mark will appear next to the device in the list, indicating the update was successful.
Important Notes When Updating
-
Do not power off or disconnect any cables during the update.
-
Always use the official Lake Controller software provided by Lab Gruppen.
-
After completion, open Lake Controller to verify that the device is operating stably with the new firmware.
Summary
Regular firmware updates are essential for maintaining optimal performance and ensuring compatibility across your Lake Frame, PLM+, or D Series systems.
By following the STEPS above carefully, you can update your devices safely, quickly, and accurately, ensuring your entire Lake system runs smoothly with maximum efficiency.
