| Receiving channels |
2 |
| Receiver principle |
Double superheterodyne |
| Diversity |
True bit diversity |
| Frequency range |
470 – 714 MHz |
| Sensitivity |
-100 dBm, typical |
| Image rejection |
> 100 dB, typical |
| Audio frequency response |
- LR mode: 30 Hz to 20 kHz (1.5 dB)
- LD mode: 30 Hz to 14 kHz (1.5 dB)
|
| Analog audio outputs |
- One XLR-3 and 6.3 mm (1/4") jack per channel (transformed-balanced)
- -10 dBu to +18 dBu in increments of 1 dB (2 kΩ)
|
| Digital audio outputs |
- AES3-2003, XLR-3: 48 kHz, 96 kHz, 24 bit
- Can be externally synchronized using WCLK loop-through with BNC sockets
|
| Headphone output |
6.3 mm jack, 2× 100 mW at 32 & OMEGA; |
| Antenna inputs |
2× BNC (50 Ω) |
| Daisy chain outputs |
- 2× BNC (50 Ω)
- 0 dB +/- 0.5 dB amplification relative to antenna inputs
|
| Daisy-chained receivers (HF) |
Max. 8 EM 6000 units |
| Booster supply voltage |
12 V DC, max. 200 mA each via antenna sockets, short circuit proof |
| Word clock input |
BNC, 75 Ω |
| Word clock output |
BNC, 75 Ω |
| Word clock sampling rates |
48 kHz, 96 kHz |
| Network |
IEEE 802.3-2002 (10/100 Mbit/s), shielded RJ-45 connection |
| Power supply |
AC 100 – 240 V, 50/60 Hz |
| Power consumption |
Max. 35 W |
| Power plug |
3-pin, protection class I as per IEC/EN 60320-1 |
| Dimensions (H × W × D with mounting elements) |
44 x 483 x 373 mm |
| Weight |
Approx. 5.2 kg |
