In certain cases, your Lake Controller or Lake Frame device may boot into Safe Mode after a failed firmware update. Don’t worry - the following procedure will guide you through safely restoring the device and correctly reinstalling the firmware.
When Does the Device Enter Safe Mode?
Safe Mode is a protective state that typically occurs when the firmware update process is interrupted due to:
In this state, the device remains powered but appears as if it is in Standby Mode and not functioning normally. Safe Mode is designed to allow firmware recovery without risking hardware damage.
Step 1: Connect the Device Directly to Your Computer
-
Disconnect the device from any shared network.
-
Use a Cat5 Ethernet cable to connect the Primary port of the Lake Frame directly to your computer.
-
On your computer, open Local Area Connection settings and assign a static IP address within the range 169.254.x.x.
-
Once connected, power on the device. The LED indicator on the network port should light up, confirming a physical connection.
Step 2: Launch the Lake Update Utility
-
Open the Lake Update Utility - the official update tool (available at labgruppen.com/support/download-software).
-
Attempt a standard firmware update.
-
If the device does not reboot or is not recognized in Lake Controller after a reset, proceed to the Safe Mode update process below.
Step 3: Perform the Safe Mode Update
If the device cannot start normally, you can manually activate Safe Mode:
-
In Lake Update Utility, double-click the Lake logo in the lower-left corner.
-
The Safe Mode option will appear.
-
Select Safe Mode, read the information carefully, then click OK.
-
Power off the device completely, then power it back on.
-
The device should now appear in the updater list with the status SAFE.
Step 4: Update the Firmware
-
Select the device marked SAFE in the list.
-
Proceed with the firmware update as usual.
-
Once completed, restart the device to finalize the recovery process.
-
If the device still does not appear, try power-cycling again or using a different computer (some network cards may not be fully compatible).
Summary
Updating firmware in Safe Mode is a crucial recovery method for Lake Controller or Lake Frame devices following a failed update. It ensures your system returns to stable operation without requiring factory service.
Following the STEPS above carefully will help you save time, retain configuration data, and safely restore your device to the latest firmware version.
