* Phase-locked Loop (PLL) synthesized tuner.
* Powered by 2 x AA batteries with 12 hrs. average battery life.
* Equipped with 4 Pin Mini XLR connector.
* LCD display with channel and battery life indicator, ID number.
* The “lock-on” function prevents tampering and RF interruption.
* Extended dynamic range and smooth frequency response.
* Noise mute and tone-key squelch.
* Compatible with Guitar cable and wireless instrument
Microphones.
SPECIFICATIONS
| Frequency Preparation |
PLL Synthesized Control |
| Carrier Frequency Range |
UHF 470~960 MHz |
| Frequency Setting |
Remoset U Ultrasonic |
| RF Outputs |
Low/High |
| Stability |
<±10KHz@ Fc |
| Frequency Deviation |
±48KHz |
| Spurious Emissions |
<-50dBc |
| Display |
LCD+LED |
| Input Connector |
MINI XLR |
| Controls |
Power ON/OFF, Mute ON/OFF, Group, Channel, Frequency, GAIN Adjust, Auto Power Off Adjust, Lock-on Mode |
| Battery |
UM3, AA x2 |
| Slot-in Charging |
Yes |
| Dimensions |
62(W) x 80.3(H) x 22.6(D) |
| Notes |
Actual product specifications may vary depending on model and region. |
* Uni-direction for high-quality voice pick-up.
* Wide dynamic range and frequency response for excellent sound reinforcement.
* Small size for minimum visibility.
* Together with clip for easy attaching to a tie, lapel, dress etc.
SPECIFICATIONS
| CM-501 |
| Connector |
4P Mini XLR |
| Frequency Response |
100~15,000 Hz |
| Polar Pattern |
Cardioid |
| Sensitivity (at 1KHz) |
-60±3 dB* (1mV)*0dB=1V/μbar |
| Impedance |
2.2k& OMEGA; |
| Max. SPL for 1% THD |
130dB |
| Dimension(mm) |
Ø10.1mm(W)* 26.4mm(H) |
| Net Weight |
21.5g |
