A. Function key B. Additional key C. The key reduction D. Confirmation key The A B C D E.LED display window Operation instructions: pressing function key A will cycle eight different functional effects. The first two digits of the digital tube represent the current function (refer to the function table). The last two numbers represent the function of this kind.address code. Or the speed, the parameters of the. Press either B or C to modify the parameter values. Press the key D to confirm.
Order
number
Show
Function declaration
1
A 0001
Address code setting, (001- -512)
Key B and C keys add or subtract the address code value
2
CHND（4CH/8CH）
Channel mode is set at 4 CH / 8 CH
3
CL01（CL01—CL15）
15 static mixed colors, (01- -99)
B, C key to modify the combination of change speed
4
CC99（CC01—CC99）
Jump self mode, (01-99)
5
EE99（EE01—EE99）
Mutation-induced self-driven mode (01- -99)
6
FF99（FF01—FF99）
Gradade mode, (01-99)
7
ST99（ST01—ST99）
Strobe self-drive mode, up and down key speed, confirmed color (CL01-CL15)
8
SUO1 (SUO1/2/3/4)
Voice control mode SOU 1 jump voice control The SOU 2 mutant sound control
SOU 3 discoloration strobe sound control
SOU 4 jump + mutation + color change strobe sound control
9
R255
Red color selection, (000- -255)
B and C key to modify the color selection
10
G 255
Green color selection, (000- -255)
11
B255
Blue color selection, (000- -255)
12
W255
White selection, (000-255)
13
FAN (ON/OFF)
ON smart fan on, OFF smart fan off, the fan is at full speed
Order number
Function
Explain
Channel 1
Total dimming
R, G, B, W total dimming, linear dimming, from dark to bright
Channel 2
R aiming
R dimming, linear dimming, from dark to bright
Channel 3
G aiming
G dimming, linear dimming, from dark to bright
Channel 4
B aiming
B dimming, linear dimming, from dark to bright
Channel 5
W aiming
W dimming, linear dimming, from dark to bright
Channel 6
stroboflash
Flashscopic effect, 0-10 closed light, (11 to 255 speed from slow to fast)
Channel 7
Effect combination
0-10 closed light, 11-50 static color mixing mode, 51-100 hopping self-walk mode, 101-150 gradual self-go mode, 151-200 mutant self-walk mode, 201-220 hopping voice-control mode, 221-240 mutant sound-control mode,
241-255 color strobe control mode
Channel 8
speed control
Speed adjustment (0 to 255 Speed from slow to fast)
The operation is very simple, humanized design, dimming without flicker, jitter phenomenon, etc. Can adapt to photography, photography, television stations and other strict requirements on the lighting occasions.
Master and slave Synchronization Notes:
When the host is used, the lamp will send the DMX-512 signal, which cannot be connected to the DMX-512 console, otherwise it will interfere with each other and cannot run synchronously.
Multiple lamps and lanterns operate synchronously, among which only one lamp is the main engine, and the other lamps are the slave machine. Otherwise, it cannot be run synchronously. Maintenance: It is recommended to use a professional glass cleaning agent and clean it with a flannelette. Keep it clean frequently to obtain the maximum LED brightness output.
