DI4800A Active DI Boxes Behringer

Mã sản phẩm: DI4800A      1.035
4.67/5 trong 3 lượt
Behringer
  • DI4800A
  • DI4800A
  • DI4800A
  • DI4800A
  • DI4800A
DI4800A
DI4800A
DI4800A
DI4800A
DI4800A

2.560.000
  • Miễn phí giao hàng toàn quốc


Documentation

·  Quick Start Guide, All Languages

·  Quick Start Guide, Chinese

·  Quick Start Guide, Japanese

SPEC

  • Professional and multi-purpose 4-channel direct injection box for stage and studio applications

  • Provides impedance and signal matching for the direct connection of instruments to mixers and amplifiers

  • Ultra-flat frequency response due to renowned Behringer OT-1 transformers

  • Total of +18 dB gain boost in three +6 dB increments for pre-amplification of low-level signals

  • Ground Lift switch eliminates typical ground loop problems

  • Switchable -20 dB output attenuation

  • Neutrik* combo and gold-plated XLR connectors

  • Powered via external DC power supply (included) with optional battery powered operation (sold separately)


    ULTRA-DI PRO DI4800A
    ULTRA-DI PRO DI4800A

    THE ULTRA-DI PRO DI4800A gives you 4 first-class DI channels in a single rack space. Each channel is equipped with one input (XLR or ¼” TRS) and two XLR Outputs at the front and back to connect to your amp or monitor console allowing for 8 outputs in all. Plus, the DI4800A is designed to accommodate virtually any input signal, with a switchable output attenuation of -20 dB, while our highly acclaimed OT-1 output transformers ensure pristine and powerful output.

    PRO-Active
    PRO-Active

    Direct Injection (DI) boxes make it possible to connect guitars, basses and keyboards (as well as other line-level devices) to audio mixers and recorders. The DI4800A takes the DI box to the next level by providing +6 dB and +12 dB gain switches for a total of +18 dB of gain boost perfect for amplifying low-level signals. The DI4800A also features a -20 dB attenuation switch per channel, gold-plated XLR output connectors which provide reliable, low-noise operation and per channel ground-lift switches to eliminate ground-loop hum issues.

    ¼” In, XLR Out – There has to be More?
    ¼” In, XLR Out – There has to be More?

    The 4-channel ULTRA DI PRO DI4800A delivers exceptional sound quality – at an extremely affordable price. Find out how the DI4800A can instantly improve your sound at your nearest Behringer dealer or place your order online today!


    Specification

    Inputs
    Connectors

    4 x XLR-1/4" combo jacks, balanced

    Impedance

    20 kΩ

    Max. input level

    +20 dBu

    Channel boost switchable

    +6 dB,+12 dB,+18 dB

    Outputs
    Connectors

    8 x XLR, transformer balanced

    Impedance

    600 Ω

    Max. output level

    +20 dBu

    Output pad switch

    20 dB attenuation

    System
    Frequency response

    20 Hz to 20 kHz (±3 dB)

    THD + N (distortion)

    0.01% @ 1 kHz, 0 dBu

    Signal-to-noise ratio

    120 dB

    Ground lift switch

    Removes ground connection

    Power requirement

    12 V DC, 500 mA

    Physical
    Standard operating temperature range

    5° C – 40° C (41° F – 104° F)

    Dimensions (W x D x H)

    483 x 71 x 44 mm

    (19.0 x 2.8 x 1.7"")

    Weight

    1.4 kg (3.1 lbs)
