Professional and multi-purpose 8-channel direct injection box for stage and studio applications
Provides impedance and signal matching for the direct connection of instruments to mixers and amplifiers
Ultra-flat frequency response due to servo-balanced operation
Optional mains or phantom-powered operation
Allows direct connection to speaker outputs with up to 3,000 Watts
+20 dB gain switch for pre-amplification of low-level signals
Switchable input attenuation allows input levels of up to +40 dB
Ground Lift switch eliminates typical ground loop problems
Link output for easy connection to further equipment
1/4" TRS and gold-plated XLR connectors
Illuminated switches enable perfect operation in dark stage environments
Internal switch-mode power supply (100 - 240 V~) for noise-free audio and low power consumption
1 -Year Warranty Program*
Designed and engineered in Germany
The ULTRA-DI PRO DI800 is a professional mains/phantom powered 8-channel active DI-box. If you need a rack-mountable DI unit with enough inputs to accommodate everyone on stage, or in the studio – then you need to plug into the DI800!
Direct Injection (DI) boxes make it possible to connect guitars, basses and keyboards (as well as other line-level devices) to audio mixers and recorders. They are absolutely essential for proper impedance-matching and to maintain signal integrity. Our active DI800 features “buffered” inputs that respect your source signal much better than passive DI boxes. Balanced signals leaving the DI800 are extremely low-impedance (typically less than 680 Ω), and far less susceptible to noise and RF Interference (RFI).
When it comes right down to it, all DI boxes do the same thing, right? Yes, in a manner of speaking, but the DI800 does much more than just �bass guitar in, mic-level signal out.� It really is a highly versatile input-signal toolkit. Here are just two advantages the DI800 has over standard passive DI boxes:
Of course, the DI800 provides a Link output for easy connection to other equipment, such as your onstage amplifiers and monitor consoles. Servo-balanced performance guarantees ultra-flat frequency response � and the gold-plated XLR output connectors provide reliable, low-noise operation. Per channel ground-lift switches eliminate ground-loop hum issues. The DI800 does everything a standalone passive DI can, and much more � times eight!
Unlike their passive counterparts, active DI boxes require a power source to make their internal electronics work. The DI800 provides two power options: 100 – 240 V~ from the nearest wall outlet or power strip, or +48 V DC from your mixer phantom power supply.
The 8-channel ULTRA-DI PRO DI800 delivers exceptional sound quality – at an extremely affordable price. Find out how the DI800 can instantly improve your sound at your nearest BEHRINGER dealer, or place your order online today!
