TKT105 Passive Speakers Tannoy

Mã sản phẩm: TKT105      405
4.67/5 trong 3 lượt
TANNOY
  • TKT105
  • TKT105
  • TKT105
  • TKT105
TKT105
TKT105
TKT105
TKT105

6.540.000

Áp Dụng Khi Thanh Toán OnLine!

Tính năng nổi bật

3 way full range loudspeaker for KTV applications
150 Watts continuous, 600 Watts peak power
High excursion 10" low frequency driver with low mass voice coil
4 wide dispersion 3 inch mid-high frequency drivers
3 Way 10" Full Range Loudspeaker for KTV Applications




Documentation

·  Product Information Document, English

·  Quick Start Guide, English

SPEC

  • 3 way full range loudspeaker for KTV applications

  • 150 Watts continuous, 600 Watts peak power

  • High excursion 10" low frequency driver with low mass voice coil

  • 4 wide dispersion 3 inch mid-high frequency drivers

  • Precision engineered crossover for maximum performance in the midrange vocal region

  • Tweeter overload protection circuit gives uninterrupted performance

  • Internal rigging points allow standard bracket mount suspension and orientation

  • 15 mm (5/8") wood enclosure with hard wearing PVC laminate finish

  • Architecturally styled powder coated perforated steel mesh grille with foam backing

  • Binding post screw terminal connectors for fast connection

  • 1-Year Warranty Program*

  • Designed and engineered in the U.K.


    TKT105
    TKT105

    The 3-way full range TKT105 is a 600 Watt 10" loudspeaker system designed specifically for KTV applications. Engineered for permanent installation, TKT105’s cabinet accommodates industry standard mounting brackets and is ideally suited for a wide range of listening environments.

    Precision and Detailed Clarity
    Precision and Detailed Clarity

    The TKT105 loudspeaker features a 10" low frequency driver with a low mass voice coil for improved transient response, and 4 wide dispersion 3 inch mid-high frequency drivers with overload protection circuitry. All drivers are matched with a high-precision passive crossover network that provides maximum performance in the midrange vocal region. The rear panel carries binding post screw terminals for quick and convenient wiring.

    Rock Solid Construction
    Rock Solid Construction

    Finished in a PVC laminate finish, the 15 mm (¼) wood cabinet also includes an architecturally styled powder coated perforated steel mesh grille backed with reticulated foam. Internal rigging points are provided for suspension or mounting with industry standard brackets - available separately.


    Specification

    System
    Frequency response 65 Hz – 18 kHz ±3 dB
    45 Hz – 16 kHz -10 dB
    Nominal dispersion 150° H x 80° V @ -6 dB points
    Power handling (IEC) 150 W continuous, 600 W peak
    Sensitivity 90 dB (1 W @ 1 m)
    Maximum SPL 112 dB continuous, 118 dB peak
    Impedance 8 O
    Components 1 x 10" (259 mm) LF driver
    4 x 3" (92 mm) HF cone paper
    Enclosure
    Connectors Binding post screw terminals
    Wiring Red: positive, black: negative
    Dimensions (H x W x D) 297 x 508 x 323 mm (11.7 x 20 x 12.7")
    Net weight 12.4 kg (27.3 lbs)
    Construction 15 mm (5/8") particle wood
    +12 mm (½ ") MDF wood
    Finish Semi matt black PVC laminating
    Grille Powder coated perforated steel
    Flying hardware M10 x 2
